Weight(Kg)	59.80 Kg
Dimensions(mm)	522×242×218×222 mm
Voltage	12-Volt
Capacity @ 1hr Rate	120.0 AH
Capacity @ 3hr Rate	150.0 AH
Capacity @ 5hr Rate	170.0 AH
Capacity @ 10hr Rate	186.0 AH
Capacity @ 20hr Rate	200.0 AH
Grid alloy	Calcium / Tin lead alloy
Plates	Flat Pasted
Separator	Absorbant Glass Mat
Active material	Very high purity lead
Case Type	ABS Plastic – Flame Res. Rating UL94-HB
Terminal Type	M8
Terminal Torque	62～80 In-lbs
Maximum Charge Current (A)	20% of C20
Internal Resistance(mΩ)	2.70 mΩ
Cyclic Charge voltage	2.40-2.45VPC （20-25°C）
Float Charge voltage	2.25-2.30VPC （20-25°C）

Fullriver’s HGL Series Battery differs from the rest because of its thicker internal plate construction and more active inner material. This makes the HGL Series Battery ideal for camping and caravan applications. The Fullriver deep-cycle battery uses a different chemistry for the plates’ active paste material, and a slightly stronger acid. This chemistry allows for much longer life in deep-cycle applications with only slightly reduced maximum power output.

Weight 25.4 lbs Dimensions 7.72 × 5.16 × 6.57 in Weight (kg) 11.5 kg

1. Dimensions (mm) 196 x 131 x 167 mm
2. Group Size U1
3. Voltage 12-Volt
4. Terminal Type M6
5. CCA 190
6. CA or MCA 230
7. Capacity @ 5hr Rate 29 AH
8. Capacity @ 20hr Rate 35 AH
9. Capacity @ 100hr Rate 39 AH
10. Reserve Capacity @ 25 Amps 52 minutes
11. Reserve Capacity @ 75 Amps
